This machine is a latest automatic foil stamping equipment. It is widely used in foil stamping with various kinds of paper and other flat materials, such as invitation card, red pocket, cartons. With foil stamping, the products can be made with more personalized and more exquisite.

Features

PLC control, easy to operate with one person.
Foil stamping pressure, temperature and time can be adjusted.
The feeding guide can be adjusted in both direction.
Foil stamping plate vertical position can be micro-adjusted through touch screen.
Servo motor for feeding, paper deliver and collecting with sensor for positioning.
Feeding and collecting table work up and down automatically.
Automatic working mode.
With safety protection, machine will automatically stop when sensing operator approaching dangerous area.

Specification

Model	TJ-450	TJ-550	TJ-550 heavy duty	TJ-780	TJ-780 heavy duty
Max. Paper size	400*400mm	550*500mm	550*500mm	750*550mm	750*550mm
Effective foil stamping size	300*280mm	300*280mm	400*400mm	500*500mm	600*500mm
Paper thickness	80-1500gsm	80-1500gsm	80-1500gsm	80-1500gsm	80-1500gsm
Working speed	15-40pcs/min	15-35pcs/min	15-35pcs/min	15-30pcs/min	15-25pcs/min
Max. pressure	1 tons	1.2 tons	30 tons	2 tons	30 tons
Temperature	0-300℃	0-300℃	0-300℃	0-300℃	0-300℃
Feeding paper height	320mm	500mm	500mm	500mm	500mm
Delivery paper height	320mm	500mm	500mm	500mm	500mm
Air supply	0.6Mpa	0.6Mpa	0.6Mpa	0.6Mpa	0.6Mpa
Power required	220V 1P	380V 3P	380V 3P	380V 3P	380V 3P
Machine weight	About 450KGS	About 750 KGS	About 1500 KGS	About 1500KGS	About 1800KGS
Machine dimension	100014501450mm	170011501600mm	170011502300mm	265014501900mm	265014501900mm
