This machine is an automatic machine with multi-running positions. It can perform all the processes of paper-feeding, sealing, oiling, bottom-punching, heating, knurling, edge rolling, and discharge. Functions like photo-electric detection, failure alarm and counting are provided by it.

Application
  • JBZ-S is suitable for double side PE coated paper cups.
  • JBS-A is ideal for single side PE coated paper cups.
Specification
Paper cup size(capacity) 4.5.6.9.12.14.16OZ
Paper cup diameter 50-80mm
Paper cup depth 65-125mm
Paper weight 130-350g/m2
Paper cup material Paper with one-sided coating or double-sided coating
Cup making speed 40-50/min
Temperature control range 0-400C
Electric heating power 2.5kw
Main motor power 1.5kw
Rolling motor power 0.55kw
Power supply 380 V /3P/50Hz or 220V/3P/50Hz
Whole machine weight 1500kg
Overall dimension 2650x1200x1500mm
