High Speed Vacuum Forming Machine, DXS Series

High Speed Vacuum Forming Machine, DXS Series
Kostenvoranschlag erhalten

DXS Series Automatic Computerized High-Speed Vacuum Forming Machine (Thermoforming machine). It is designed by the principle of mechanical-electrical- pneumatic integration. Adopts PLC control system, panel and AC voltage meter adjustment. It is full-automatic forming equipment for thermoforming plastic sheet includes feeding, heating; forming, cooling, mold ejecting, cutting at one blow. These machines have luxury configuration and gets reliable performance and handy operation.

Features

It is suitable for thermoforming PS, HIPS, PVC, PET, PP, flocking sheet that can produce varieties of blister package and blister tray. For example: egg tray, curatorial injection tray, oral liquid tray, mobile telephone tray, cookies tray, egg tray, one-off tableware etc.

Specification
Model
DXS-700/1200A-1
DXS-700/1200A-2
Length of forming 760-1200mm 760-1200mm
Width of forming 500-700mm 500-700mm
Height of forming ≤165 mm ≤165 mm
Production speed 60-720 Cycles/h 60-720 Cycles/h
Power consumption of oven 24Kw Upper oven 24Kw Lower oven 18Kw
Power consumption of vacuum pump motor 3Kw 3 KW
Pump speed of vacuum 100m3/h 100m3/h
power consumption of air compressor 15KW 15KW
Capacity of air compressor 1.5m3/min 1.5m3/min
Voltage 380/220V 50HZ 380/220V 50HZ
Overall dimensions 7950x1450x2550mm 7950x1450x2550mm
Weight 3000kg 3500Kg
