This flexographic printing machine is widely used in adhesive label printing and also plastic sleeve label printing.

Features
  • Adopt the ceramic anilox roller to transfer the ink.
  • Unwinding and rewinding are controlled by magnetic powder brake/clutch.
  • Each printing unit adopts 360°plate-adjustment.
  • Each printing unit is equipped with IR dryer
  • This printing machine equips one die-cutting station to complete printing and die-cutting at one stroke.
  • The ink rollers will be separated from the printing rollers, and keep running when the machine stops.
  • Main motor adopts imported inverter.
Application
  • This kind of converting machinery is widely used to print notes and top-grade adhesive labels for printing houses.
  • It can perform the processes of material-feeding, printing, varnishing, drying, laminating, die-cutting, rewinding and sheetering in one go.
Specification
Model
ZBS-320
ZBS-320G
Printing speed: 50m/min 55m/min
Printing colour : 5colours 5colours
Max. web width : 320mm 320mm
Max. printing width: 310mm 310mm
Max. unwinding diameter: 600mm 650mm
Max. rewinding diameter: 600mm 650mm
Printing perimeter: 175-355mm 175-355mm
Precision of chromatography: ±0.1mm ±0.1mm
Dimensions: 2(L)x1.1(W)x2.6(H)(m) 2.6(L)x1.1(W)x2.6(H)(m)
Machine weight: about 2200kg about 3100kg
