Stützrollen - PWTR Serie
Kostenvoranschlag erhalten
| Lager-Code | Tragzahl | Grenzdrehzahl | Masse | ||||||
| d | D | B | C | d2 | Crw | Corw | |||
| mm | mm | mm | mm | mm | N | N | KG | ||
| PWTR15-2RS | 15 | 35 | 19 | 18 | 20 | 11900 | 14600 | 6000 | 99 |
| PWTR1542-2RS | 15 | 42 | 19 | 18 | 20 | 13900 | 15200 | 6000 | 158 |
| PWTR17-2RS | 17 | 40 | 21 | 20 | 22 | 13600 | 17200 | 5000 | 147 |
| PWTR1747-2RS | 17 | 47 | 21 | 20 | 22 | 15100 | 17200 | 5000 | 220 |
| PWTR20-2RS | 20 | 47 | 25 | 24 | 27 | 23800 | 30500 | 3800 | 245 |
| PWTR2052-2RS | 20 | 52 | 25 | 24 | 27 | 26000 | 34000 | 3800 | 321 |
| PWTR25-2RS | 25 | 52 | 25 | 24 | 31 | 24600 | 33000 | 3800 | 281 |
| PWTR2562-2RS | 25 | 62 | 25 | 24 | 31 | 29000 | 40500 | 3800 | 450 |
| PWTR30-2RS | 30 | 62 | 29 | 28 | 38 | 34000 | 45500 | 2200 | 465 |
| PWTR3072-2RS | 30 | 72 | 29 | 28 | 38 | 40000 | 54000 | 2200 | 697 |
| PWTR35-2RS | 35 | 72 | 29 | 28 | 44 | 38000 | 54000 | 1800 | 630 |
| PWTR3580-2RS | 35 | 80 | 29 | 28 | 44 | 42500 | 64000 | 1800 | 836 |
| PWTR40-2RS | 40 | 80 | 32 | 30 | 50.5 | 43500 | 61000 | 1500 | 816 |
| PWTR4090-2RS | 40 | 90 | 32 | 30 | 50.5 | 51000 | 75000 | 1500 | 1129 |
| PWTR45-2RS | 45 | 85 | 32 | 30 | 55.2 | 44500 | 63000 | 1300 | 883 |
| PWTR45100-2RS | 45 | 100 | 32 | 30 | 55.2 | 55000 | 85000 | 1300 | 1396 |
| PWTR50-2RS | 50 | 90 | 32 | 30 | 59.8 | 44500 | 66000 | 1100 | 950 |
| PWTR50110-2RS | 50 | 110 | 32 | 30 | 59.8 | 58000 | 94000 | 1100 | 1690 |
