Shrink Sleeve Label Seaming Machine (Mold-less Type), GSHZ300C
Kostenvoranschlag erhalten
This shrink sleeve seaming machine is designed for gluing / seaming single layer PVC/PET roll to produce various shrink sleeve label such as beverage label, battery sleeve, pens sleeve, etc. This stand alone machine operates at 300 meter per minute and forms the sleeves via an adjustable forming section. The machine is available in 300mm and or other customized size lay-flat models. It features fast changeover rewind and unwind air shafts. It has unwind perforation & edge guide for solvent needle sold for top converting practices.
Features
- It has two gluing system with alternative using.
- It is equipped with movable controller
- Mold-adjustable system easy for different sizes changing.
- It has ultrasonic EPC Web guiding system, which provides the accuracy shrink sleeve seaming position.
- It has stroboscope and photo sensor to help monitoring the sealing quality.
- It can be equipped with vertical continuous perforation device and rewind oscillation device
Specification
| Forming Width | 70~300mm |
| Unwinding diameter | 500mm |
| Rewinding diameter | 700mm |
| Mechanical speed | 330m/min |
| Max seaming speed | 300m/min |
| Material Core Inner Diameter | 76 / 3" |
| Total power | 5.5kw |
| Voltage | 380v/50hz |
| Machine weight | 1800kg |
| Overall dimension | 2950×1550×1700mm |
