This Side sealing cutting bag making machine is suitable for heat cutting and side sealing printed or without printed plastic film (OPP, PP, PE, PET), it is a kind of ideal equipment for making garment bag, towel bag, bread bag and cosmetic bag, etc

Features
  • The whole machine adopts microcomputer control and material pulling by step motor (option: Servo motor control system)
  • With the functions: length positioning, photocell tracking, automatic stop when lose tracking mark.
  • Add double side adhesive tape in same process, automatic punching.
  • Heat dot sealing, automatic constant control temperature, with firm and smooth sealing.
  • Tube film edge cutting, bag top flap folding, bottom insert, heat pressing.
  • Ultrasonic embossing, pearlized film inserting function.
Specification
Model
DRQ500G
DRQ600G
DRQ700G
DRQ800G
DRQ1000G
Bag length 50~700mm 50~700mm 50~700mm 50~700mm 50~700mm
Max width 500mm 600mm 700mm 800mm 1000mm
Speed 60~200pcs/min depend on bag making size and material
Total power 3.5kw 4kw 5kw 5.5kw 6kw
Dimension 3.7x1.2x1.5m 3.7x1.3x1.5m 3.7x1.4x1.5m 3.7x1.5x1.8m 3.7x1.7x1.8m
Weight 800kg 850kg 900kg 950kg 1000kg
