Vierreihige Zylinderrollenlager

Kostenvoranschlag erhalten

Über uns: http://bearingfactory.de/2-3-four-row-cylindrical-roller-bearings.html

Lager-Code	Referenzindex					Grundmaß (mm)						Tragzahl		Masse
	SKF	FAG	NTN	NSK	KOYO	d	D	B	Fw	r1.2min	r3.4min	Cr	Cor	Kg
FC100130260	319254/VJ202					500	650	260	542	6	6	4020	10200	225
FC3042120						150	210	120	166	2	2	587	1380	12.5
FC3044120						150	220	120	167	2	2	702	1193	15.5
FC3044150			4R3031	150RV2201	30FCC22150A	150	220	150	168	2	2	701	1700	19.3
FC3045120						150	225	120	169	2	2	702	1408	16.2
FC3045150						150	225	150	169	2	2	801	1670	20.9
FC3046130			4R3029			150	230	130	174	2	2	670	955	19.7
FC3046150						150	230	150	177	2	2	950	1790	22.8
FC3046156	313891A	508955	4R3040	150RV202	313891-1	150	230	130	174	2	2	825	1810	24
FC3244180			4R3224			160	220	180	177	2.1	2.1	940	2560	20.2
FC3245120						160	225	120	177	2.1	2.1	639	1340	14.9
FC3246130				160VR2301		160	230	130	178	2.1	2.1	781	1320	17.7
FC3246130E	314190	541515	4R3226			160	230	130	180	2.1	2.1	781	1340	17
FC3246168						160	230	168	177	2.1	2.1	895	2200	22.8
FC3246168E	315189A	510150	4R3232			160	230	168	179	2.1	2.1	1050	2170	23.5
FC3246168E1				160RV2302	32FC23170A	160	230	168	180	2.1	2.1	895	2200	23.5
FC3246180					32FC23180	160	230	180	178	2.1	2.1	838	2270	24.6
FC3248120						160	240	120	183	2.1	2.1	635	1301	18.6
FC3248124						160	240	124	183	2.1	2.1	635	1301	19.6
FC3248168						160	240	168	183	2.1	2.1	1042	2310	26.7
FC3248170			4R3225			160	240	170	183	2.1	2.1	980	2290	27.8
FC3446120			4R3426			170	230	120	187	2	2	819	1580	14.3
FC3446130	313673					170	230	130	188.5	2	2	670	1400	15.6
FC3446180						170	230	180	186	2.1	2.1	1034	2035	24.5
FC3448130	BC4B635122					170	240	130	190	2.1	2.1	913	1830	18.7
FC3448156			4R3429			170	240	156	189	2.1	2.1	905	2170	22.2
FC3450150						170	250	150	192	2.1	2.1	720	1716	25
FC3450168				170RV2502	34FC25168	170	250	168	192	2.1	2.1	1040	2320	28
FC3450170					34FC25170	170	250	170	192	2.1	2.1	1170	2428	28.6
FC3451180			4R3425	170V2503		170	255	180	193	2.1	2.1	1380	2500	30.5
FC3452120						170	260	120	195	2.1	2.1	860	1752	23
FC3452150						170	260	150	195	2.1	2.1	883	1803	28.8
FC3452170						170	260	170	195	2.1	2.1	1034	2096	32.7
FC3452192						170	260	192	195	2.1	2.1	1087	2240	36.9
FC3452225	313587B	505470	4R3431			170	260	225	196	2.1	2.1	1650	3310	43.3
FC3650120						180	250	120	200	2.1	2.1	610	1578	18
FC3650130	19.5					180	250	130	200	2.1	2.1		716	1922
FC3650156	23.4					180	250	156	198	2.1	2.1		880	2230
FC3650156E	22.8			4R3625	180RV2501	180	250	156	200	2.1	2.1		880	2230
FC3652120	21					180	260	120	202	2.1	2.1		735	1577
FC3652124	21.7					180	260	124	202	2.1	2.1		735	1577
FC3652156	27.3					180	260	156	198	2.1	2.1		835	2200
FC3652160	28.4					180	260	160	202	2.1	2.1		880	2230
FC3652168	29.5	313812	507536	4R3628	180RV2601	180	260	168	202	2.1	2.1		990	2300
FC3653180	33.8					180	265	180	204	2.1	2.1		1040	2649
FC3656180	41.4					180	280	180	207	2.1	2.1		1287	2995
FC3656180E	41		524372			180	280	180	206	2.1	2.1		1287	2995
FC3852168	24.9					190	260	168	208	2.1	2.1		1140	2520
