A4 Copy Paper Cross Cutting & Wrapping Machine, DTCP-A4

A4 Copy Paper Cross Cutting & Wrapping  Machine, DTCP-A4
A4 Copy Paper Cross Cutting & Wrapping  Machine, DTCP-A4
Kostenvoranschlag erhalten

The A4 copy paper cutting and packing machine DTCP-A4 effectively shortens the cutting and packaging time, which is conducive to the high productivity of the paper cutting machine. The production process includes paper unwinding, paper cutting, counting, paper conveying, paper unloading, and packaging. The high automation reduces the labor intensity greatly.

Features
  • The A4 copy paper cutting and packing machine can be designed according to customer demand on productivity and function.
  • This A4 copper processing equipment integrates the function of electric automation, PLC control, and mechanical automation.
  • Equipped with high-speed paper feeding rack, the A4 copy paper packing equipment has high production capacity up to 40 packages per minute.
  • We are the first manufacturer in the industry who employs nodular cast iron for heavy-duty operation, which guarantees the productivity, accordingly.
  • The cutting accuracy can be perfectly controlled within the range of ±0.2mm.
Specification
Model
DTCP-A4-5
DTCP-A4-10
DTCP-A4-20
DTCP-A4-30
DTCP-A4-35
DTCP-A4-40
Cutting Device
Quantity of feeding roller 1 2 4 5 5 5
Quantity of cutter for lengthwise cutting 4 4 4 4 5 6
Max. paper roll width (mm) 846 846 846 846 1056 1266
Net width of paper roll (mm) 840 840 840 840 1050 1260
Paper roll dia. (mm) 400-1200
Paper core dia. (mm) 3"(76.2mm) or 6"(152.4mm)
Paper weight (gsm) 60-100
Paper length (mm) 297
Number of sheet per ream (pcs) 0-500
Max. thickness per ream (mm) 65
Max. design speed (m/min) 220 220 220 305 375 330
Cutting speed (m/min) 180-220 180-220 180-220 200-260 200-260 200-260
Cutting frequency (times/min) 437 437 437 650 650 800-100
Production capacity (packages/min) 1-1.5 2.5-3 5-6 5-7 6-7 6-8
4-5 8-10 16-20 25-30 28-35 35-40
Max. cutting capacity (Paper weight) 400gsm
Cutting accuracy (mm) ±0.2
Paper roll 1. Stable paper feeding speed 2. Little paper breakage 3. Acceptable paper quality
Transmission The A4 copy paper cutting and packing machine supports AC variable frequency stepless speed control.
Main power source 380V, 50Hz, 3-phase 4-wire
Power supply 220V AC/22V DC
Installed capacity (kW) 18 22 22 22 22 30
Compressed air consumption (NL/min) 300
Compressed air pressure (bar) 0.6-0.8
Machine size (m) (L×W×H) 9×2.75×2.1 16×2.75×2.1 16.5×2.75×2.1 18.5×2.75×2.1 20×2.96×2.1 20×2.96×2.1
Machine weight (ton) 10 12 15 18 19 22
Packaging Device for A4 Copy Paper Cutting and Packing Machine
Packaging speed (packages/min) 4-5 8-10 16-20 25-30 28-35 35-40
Package size(mm) (500 pieces of A4 copy paper) 210×297×50
Power supply 380V, 50Hz, 3-phase 4-wire
Motor power (kW) 6.5
Power of glue sprayer (kW) 2.25 2.25 2.25 2.25 2.25 2.75
Compressed air pressure (MPa) 0.6-0.8
Size of wrapping paper (mm) (L×W) 550-560×386
Machine size (m) (L×W×H) 3.4×3.3×1.6 3.4×3.3×1.6 4.5×3.0×1.5 4.5×3.0×1.5 4.5×3.0×1.5 4.5×3.0×1.5
Machine weight (ton) 2 2 2 2 2 2
