Heavy Duty Type Three Side Sealing Machine, 600ZF SZ

Heavy Duty Type Three Side Sealing Machine, 600ZF SZ
Heavy Duty Type Three Side Sealing Machine, 600ZF SZ
Heavy Duty Type Three Side Sealing Machine, 600ZF SZ
Kostenvoranschlag erhalten

This three side sealing bag making machine can make center sealing bag, central sealing bag with side gusset, 4 sides sealing bag, and side sealing bag with gusset, 3 sides sealing bag, single film folding stand up bag and zipper bag.

Specification
Length of bag making 70-380mm
Width of bag making 100-580mm
Dimension of roll material ф800*1220mm (diameter* web-width)
Accuracy of orientation ≤± 0.5mm
Speed of machine 150 hypo-minute
Speed of feeding ≤45 m/min (according to the material)
Quantity of temperature heating 12 groups
Bound of temperature 0-300 ℃
Total power 34kw
Machine dimension (L*W*H) 10000X1800X1700mm
Wight About 4220kg
Color White color of frame red door
Type of control system SSF-2 high speed laminating film bag making machine control system
