Anschluss für Druckmessschlauch
Kostenvoranschlag erhalten
Andere Namen für Schlaucharmaturen für Druckprüfung kann auch als Anschluss für Druckmessschlauch und Hydrotestschlauchkupplungen genannt.
1.| | G | Bestellcode |
| M12x1.25 | H0100 | |
| M16x2.0 | H0200 | |
| M14x1.5 | H0300 | |
| M16x1.5 | H0400 | |
| | G | Bestellcode |
| M12x1.25 | H0190 | |
| M16x2.0 | H0290 | |
| M14x1.5 | H0390 | |
| M16x1.5 | H0490 |
| | G | Ch | Bestellcode |
| M12x1.25 | 19 | H0100 - 1 | |
| M16x2.0 | 19 | H0200 - 1 | |
| M14x1.5 | 19 | H0300 - 1 | |
| M16x1.5 | 19 | H0400 - 1 | |
| | G | Ch | Bestellcode |
| M12x1.25 | 19 | H0190 - 1 | |
| M16x2.0 | 19 | H0290 - 1 | |
| M14x1.5 | 19 | H0390 - 1 | |
| M16x1.5 | 19 | H0490 - 1 |
| G | Ch | Bestellcode |
| M14x1.5 | 17 | P0100 | |
| M20x1.5 | 24 | P0200 | |
| G1/4" | 17 | P0300 | |
| G1/2" | 27 | P0400 | |
| G | Ch | Bestellcode |
| M14x1.5 | 17 | P0190 | |
| M20x1.5 | 24 | P0290 | |
| G1/4" | 17 | P0390 | |
| G1/2" | 27 | P0490 |
| | G | Ch | Bestellcode |
| M14x1.5 | 17 | A01 | |
| M20x1.5 | 24 | A02 | |
| G1/4" | 17 | A03 | |
| G1/2" | 27 | A04 | |
| M16x1.5 | 19 | A05 |
| | G | CH | Bestellcode |
| NPTF1/4"-18 | 19 | W01 | |
| NPTF1/2"-14 | 24 | W02 |
| | G | Ch | Bestellcode |
| G1/8" | 12 | D01 | |
| G1/4" | 17 | D02 |
| G | Ch | d | Bestellcode |
| M12x1.5 | 14 | 6 | Q 01 | |
| M14x1.5 | 17 | 6 | Q 02 | |
| M14x1.5 | 17 | 8 | Q 03 | |
| M16x1.5 | 19 | 8 | Q 04 | |
| M16x1.5 | 19 | 10 | Q 05 | |
| M18x1.5 | 22 | 10 | Q 06 | |
| M18x1.5 | 22 | 12 | Q 07 |
| G | Ch | Bestellcode |
| 7/16 - 20UNF | 14 | C01 | |
| 1/2 - 20UNF | 17 | C02 | |
| 3/8 - 24UNF | 12 | C03 | |
| 9/16 - 18UNF | 19 | C04 |
| Φ | Bestellcode |
| 4 | B0100 | |
| 6 | B0200 | |
| 8 | B0300 | |
| 10 | B0400 | |
| Φ | Bestellcode |
| 4 | B0190 | |
| 6 | B0290 | |
| 8 | B0390 | |
| 10 | B0490 |
| d | Bestellcode |
| M08x1.00 | J01 | |
| M10x1.00 | J02 | |
| M14x1.50 | J03 | |
| G1/4" | J04 | |
| G1/8" | J05 |
| G | Ch | Bestellcode |
| M8x1 | 12 | E01 | |
| M10x1 | 14 | E 02 | |
| M12x1.5 | 14 | E 03 | |
| M14x1.5 | 17 | E 04 | |
| M16x1.5 | 19 | E 05 | |
| G1/8" | 14 | E 06 | |
| G1/4" | 17 | E 07 | |
| 7/16 - 20UNF | 12 | E 08 |
| G | Ch | Bestellcode |
| R1/8"-28 | 12 | Z01 | |
| R1/4"-19 | 17 | Z 02 | |
| NPT1/8"-27 | 12 | Z 03 | |
| NPT1/4"-18 | 17 | Z 04 |
| Φ | Bestellcode |
| 3.3 | T01 |
