Zweireihige Pendelrollenlager

Kostenvoranschlag erhalten

Über uns: http://bearingfactory.de/5-3-double-row-ball-slewing-bearing.html

Lagerbezeichnung		Abmessung (mm)				Angegebene Tragzahl (KN)		Grenzdrehzahl (rpm)		Montagemaß (mm)			Masse (kg)
Zylinderische Bohrung	Kegelige Bohrung	d	D	B	rsmin	Cr	Cor	Fett	Öl	da(min)	Da(max)	ra(max)	Masse (kg)
21304CA	21304CAK	20	52	15	1.1	31.7	32.1	6000	7500	27	45	1	0.175
21304CTN1	21304KCTN1	20	52	15	1.1	35.8	35.2	6000	7500	27	45	1	0.161
21305CA	21305CAK	25	62	17	1.1	42.7	45.5	5300	6700	32	55	1	0.277
21305CTN1	21305KCTN1	25	62	17	1.1	45.5	45.8	5300	6700	32	55	1	0.258
21306CA	21306CAK	30	72	19	1.1	57.5	63.9	4500	6000	37	65	1	0.412
21306CTN1	21306KCTN1	30	72	19	1.1	63.8	65.4	4500	6000	37	65	1	0.391
21307CA	21307CAK	35	80	21	1.5	65.4	75.4	4000	5300	44	71	1.5	0.542
21307CTN1	21307KCTN1	35	80	21	1.5	74.4	77.7	4000	5300	44	71	1.5	0.507
21308CA	21308CAK	40	90	23	1.5	88.8	99	3600	4500	49	81	1.5	0.75
21308CC	21308CCK	40	90	23	1.5	88.8	99	3600	4500	49	81	1.5	0.743
21308CTN1	21308KCTN1	45	90	23	1.5	93.9	102	3600	4500	49	81	1.5	0.717
21309CA	21309CAK	45	100	25	1.5	105.7	118.4	3200	4000	54	91	1.5	1.02
21309CC	21309CCK	45	100	25	1.5	105.7	118.4	3200	4000	54	91	1.5	1
21309CTN1	21309KCTN1	45	100	25	1.5	111.2	123.6	3200	4000	54	91	1.5	0.949
21310CA	21310CAK	50	110	27	2	123.6	144.2	2800	3800	60	100	2	1.3
21310CC	21310CCK	50	110	27	2	128.7	144.2	2800	3800	60	100	2	1.3
21310CTN1	21310KCTN1	50	110	27	2	128.7	144.2	2800	3800	60	100	2	1.22
21311CA	21311CAK	55	120	29	2	146.3	175.1	2600	3400	65	110	2	1.65
21311CC	21311CCK	55	120	29	2	146.3	175.1	2600	3400	65	110	2	1.65
21311CTN1	21311KCTN1	55	120	29	2	149.3	170	2600	3400	65	110	2	1.57
21312CA	21312CAK	60	130	31	2.1	166.9	200.9	2400	3200	72	118	2.1	2.08
21312CC	21312CCK	60	130	31	2.1	166.9	200.9	2400	3200	72	118	2.1	2.08
21312CTN1	21312KCTN1	60	130	31	2.1	175.1	200.9	2400	3200	72	118	2.1	1.96
21313CA	21313CAK	65	140	33	2.1	187.5	234.8	2200	3000	77	128	2.1	2.57
21313CC	21313CCK	65	140	33	2.1	187.5	234.8	2200	3000	77	128	2.1	2.57
21313CTN1	21313KCTN1	65	140	33	2.1	198	235	2200	3000	77	128	2.1	2.45
21314CA	21314CAK	70	150	35	2.1	218.4	276	2000	2800	82	138	2.1	3.11
